Metal Slider 4 Buttons Copy Remote Control 015A

Product Description

Product description 1) Fixed frequency: 315MHz or 433MHz; 2) Adjust frequency range:280MHz---450MHz; 3) Copy remote control,need work with the remote master. Product Notes 1) The copy remote control need work with the remote master.Pls view the details of remote master to show you how to use them. 2) Sub-RC A: fit for auto fixed code such as AX5326-3、PT2262、PT2260、EV1527、FP527、PT2240、PT2242、HT600、HT680、HT6010、HT6012、HT6012、AX5326-4,etc.. 3) Sub-RC B: fit for auto fixed code,and partial computer code,such as HT640、PT2282、PT2292 etc. 4) Sub-RC C: fit for rolling code,such as HCS300、HCS301、HCS302 etc. The steps: 1) Connect and switch on the power supply 2) Press the 5 th key twice and press the 1st key once 3) Begin to input the client’s 1st key (Press the key until the frequency displayed) press the 5th key once. Input the client’s 2nd key press the 5th key once input the client’s 3rd key the rest deduced, having finished the inputing process, press the 5th key twice—USE NO.”X” remote having inserted NO..”X” remote, Press the 5th key twice—WRITE OK 4) Pull out the remote, press the duplicator 4th key—FREQ MHz 5) Put the copied remote on the duplicator, press any key once---APPEARING FREQUENCY 6) Put the new remote on the duplicator, use ceramic aligner tool to rurn round while capacitance until the digital reach the copied remote. Having finished the adjustment, press the 1st and 2rd onceat the same time, the light flash once, then press any key, the light light, over Notes: Need to combined with car remote control duplicator (S-CMS-5010A/S-CMS-5010B) to use

Specifications

SKU

S-CMS-5017

Category

In Car › Alarm Systems & Security › Remote Control

Weight

0.051 kg

Delivery

Standard delivery
