SATLINK WS6933 Portable Digital Satellite Finder Meter, 2.1 inch LCD Colour Screen, DVB-S2/S Signal Pointer(EU Plug)

Product Description

1. 2.1 inch LCD screen display, 240(RGB)x320 TFT positive transflective, 36.72(W)x48.96(H)MM2 active area. 2. Input frequency 950~2150MHz. 3. Input Level -65~ -25dBm, input impedance 75 ohm. 4. Measurement type: Signal strength, quality; ber; pwr. 5. Sound for locking dignal. 6. Support DISEQC 1.0 /1.1 and 22khz tone. 7. LNB Power Supply: 18/13V(Max 300mA). 8. Beep Integrated. 9. 7.4V/800mAh lion battery included, max operating time: 3 hours. 10. DC adapter: Output: DC12V/1A, Input: 100-240VAC 50/60Hz, USB port for software upgrades, data protocol: USB to RS-232. 11. Band switch control: 22KHz. 12. Demodulation type: QPSK, 8PSK. 13. Power consumption: Max. 5W. 14. Connector type: F type.

Specifications

SKU

SAF6933

Category

Consumer Electronics › TV Receivers › Satellite Finder

Weight

0.714 kg

Delivery

Standard delivery
