Waveshare Adjustable Regulated Power Supply, DC Output 80V 6A

Product Description

Overview This is a regulated power supply with adjustable output. It accepts selectable 110V / 220V AC input, and then provides adjustable 0~80V DC output, the output current is up to 6A. There is also a 3-digit LED display to show the output voltage. Features 1. Strengthened aluminium alloy case, reliable & durable 2. Effective cut-out on the case body, better heat sinking, nice looking 3. Built-in temperature controlled cooling fan, automatically on / off according to the temperature 4. 3-digit LED display for monitoring the output voltage, high accuracy 5. Output voltage adjustment knob, allows to adjust the output voltage at any time 6. 110V / 220V AC input, selected by onboard switch, 220V by default Specifications 1. Product type: Adjustable power supply 2. Input voltage: AC 110V/220V±15% 47~63Hz 3. Output voltage: 0~80V (adjustable) 4. Output current: 6A 5. Rated power: 480W 6. Over load protection: 105%～200% (rated load), auto recover 7. Over voltage protection: 115%～135% (rated output voltage) 8. Short circuit protection: auto recover 9. Dimension: 21.5mm × 11.5mm × 5mm 10. Operating environment: -10℃～50℃, 20%～90%RH (non-condensing) Application 1. DC devices 2. DC motor stepless speed adjustment 3. LED stepless brightness adjustment 4. Science test 5. Student experiment

Specifications

SKU

ZY14280106

Category

Consumer Electronics › Electronics Module › Modules Expansions Accessories

Weight

1.113 kg

Delivery

Standard delivery
