Waveshare DHT11 Temperature-Humidity Sensor

Product Description

Temperature-Humidity Sensor, DHT11 Onboard Overview This is a calibrated digital temperature and humidity module with onboard sensor DHT11. It can be used for detecting ambient temperature and humidity, through the standard single-wire interface. Specifications 1. Temperature - Resolution : 1 degree C - Accuracy : +/-2 degree C - Measuring range : 0 degree C ~ 50 degree C 2. Humidity - Resolution : 1%RH - Accuracy : +/-5%RH (0~50 degree C) - Measuring range : 20%RH ~ 90%RH (25 degree C) 3. Operating voltage : 3.3V ~ 5.5 V 4. Recommended storage condition - Temperature : 10 degree C ~40 degree C - Humidity : 60%RH or below Applications 1. Weather station 2. Humidity controller 3. Test & detection device How to Use In the case of working with a MCU: 1. VCC: 3.3V ~ 5.5V 2. GND: GND 3. DOUT: MCU.IO Package Contents 1. DHT11 Temperature-Humidity Sensor x1 2. 3-pin custom connector jumper wire x1

Specifications

SKU

ZY16357373

Category

Consumer Electronics › Electronics Module › Modules Expansions Accessories

Weight

0.012 kg

Delivery

Standard delivery
