A4058 12V 7Pin AU Plug Socket Wiring Connector Adapter Plug Socket for Trailer / RV

Product Description

1. Function: connect truck and power supply, suitable for trailer signal light display 2. Installation position: between the conductive tractor and the towed vehicle 3. Scope of application: trailers, trucks, trucks 4. Parameters: Material: ABS+copper Voltage: 12v Power: 2w Waterproof rating: IP67 Number of needles: 7 5. Connection method: PIN 1-yellow wire (left turn signal light display) PIN 2-black wire (reversing signal light display) PIN 3-White wire (ground) PIN 4-green wire (right turn signal light display) PIN 5-blue line (service brake display) PIN 6-red wire (brake light display) PIN 7-brown wire (rear light, illuminator and side light display)

Specifications

SKU

EDA0013964

Category

In Car › Replacement Parts › Terminal connectors

Weight

0.055 kg

Delivery

Standard delivery
