AMD A68P + FM2b DDR3 Computer Motherboard Supports FM2 / FM2 + HDMI VGA USB3.0

Product Description

1. AMD A68H main chipset, AMD A68H chipset. 2. Number of CPU slots: 1, CPU slot type: Socket FM2+/FM2. 3. Support FM2/FM2+ interface, AMD Trinity A /Richland/Kaveri APU processor A10/A8/A6/A4/Athlon CPU. 4. Video interface: VGA / HDMI. 5. Memory type: DDR3, memory description: Support DDR3 1066/1333/1600/1866. 6. Integrated chip: graphics card / sound card / network card. 7. Audio chip: Integrated Realtek ALC six-channel audio chip. 8. Graphics chip: CPU built-in display chip (requires CPU support). 9. NIC chip: Onboard 100M NIC. 10. 7 USB ports, 3 fronts. 11. 1 front USB 3.0. 12. PCI-E graphics card slot. 13. No IDE slot, no FDD slot. 14. Keyboard and mouse interface: PS/2 round interface. 15. External port: VGA / HDMI / USB / PS2 / audio interface / network card. 16. 2-4 SATAIII interfaces. 17. Memory slot: 2 x DDR3 DIMM. 18. Micro ATX form factor. 19. Power socket: one 4-pin, one 24-pin. Note: You should not put the case on the chassis, no screws. In order to prevent the goods from meeting your needs, you can also return the goods. When testing the installation, you need to gently screw up.

Specifications

SKU

PC4788

Category

Computer & Networking › Computer Components › Motherboard

Weight

0.908 kg

Delivery

Standard delivery
