F3088-20A 20A Manual Reset Circuit Breaker Double Short Legs with Bolt 12/24V

Product Description

1. Rated voltage: 6-28V 2. Bolt length: 37in (9.4mm); bolt spacing: 69in (17.5mm);Wing mounting hole spacing: 1.56in (39.6mm) 3. Interrupt rating: 2.5KA @ 12Vdc 4. Operating temperature: -40-85 degrees centigrade 5. Torque level: 15in-lb 6. IP66 waterproof: IP66 on plastic cover(except for terminal) 7. Applications: battery chargers, stereos, cars, trucks, buses, ships, recreational vehicles, trailer motors, etc.

Specifications

SKU

CMS0395

Category

In Car › Replacement Parts › Fuse

Weight

0.024 kg

Delivery

Standard delivery
