NICETY Coating Thickness Gauge for Measurement of Electrically Non-conductive Coating on Non-ferrous Metals (CM8802N)

Product Description

NFe type is used for measurement of electrically non-conductive coating on non-ferrous metals, e.g., paint, plastic coating and anodic oxide film on aircraft, car, home appliances, aluminum alloy door and window, or other aluminum product. When the coating has slightly electrical conductivity, and if the electrical conductivity of the coating and substrate differs at least 3 times, e.g., chrome layer on copper. Gage can measure it too, Stainless Steel belong to this type not Fe type 1) Range: 0-1250um 0-49mils 2) Resolution: 1um / 0.1miles 3) Accuracy: +/-(3%H+2um), H-standard coating thickness 4) Battery: 2 x AAA (not include) 5) Size: 11.9cm x 4.5cm x 2.7cm

Specifications

SKU

S-DT-0010

Category

Consumer Electronics › Test Equipment › Coating Thickness Gauge

Weight

0.3 kg

Delivery

Standard delivery
