Sunhans eSunRC 2000mW 2.4GHz&5.8GHz Dual Band WiFi Booster

Product Description

1. Material: cast aluminum 2. Booster model: SH-RC5824G2W 3. Operating frequency: 2.4-2.5 GHz, 5.0-5.875 GHz 4. Working mode: bidirectional, half-duplex, time division duplex, can sense radio frequency, carrier from transmitter, and automatically switch between receiving and transmitting modes. 5. Interface type: SMA socket 50ohm, 6. Connect to radio: SMA female (inner hole), 7. Connect to antenna: RP-SMA female (inner pin) 8. Input power: 0-20 dBm 9. Transmitting gain: 15-18dB 10. Output power: 2000mW (33dBm) 11. Receiving gain: about 12 dB 12. Noise figure: about 3.5 dB (typical value) 13. Frequency response: ?±1dB within the working range 14. Support voltage: 5V~16V/2A DC 15. Working temperature: -20 degrees Celsius to 70 degrees Celsius 16. Working humidity: up to 75% relative humidity 17. 2.4G and 5.8G dual-band, automatic frequency switching 18. Maximum 2000mW actual output power, support different power supplies 19. Aluminum alloy shell, CNC Fine processing, anti-interference 20. Lightweight and compact, can be easily installed on DJI drones, XIRO drones and remote controllers 21. Plug and play, no software installation required 22. Designed for drones, unmanned aircraft and remote control devices 23. Suitable for routers, IP cameras, remote control helicopters, remote control racing boats, Bluetooth, walkie-talkies

Specifications

SKU

EDA0078899

Category

Computer & Networking › Networking Accessories › Broadband Amplifiers

Weight

0.094 kg

Delivery

Standard delivery
