SUNWEIT ST7206 M.2 A+E RTL8125BG Single Port RJ45 2.5G Quad Speed Industrial Network Card

Product Description

1. Combines a quad-speed IEEE802.3-compatible media access controller with a quad-speed Ethernet transceiver, compliant with 10/100Mbps Ethernet IEEE802.3u, IEEE802.3ab 1000Mbps, IEEE802.3bz 2500Mbps Ethernet specifications 2. Provides high-speed transmission via CAT5e UTP cable or CAT3 UTP (10Mbps only) cable 3. Suitable for desktops, workstations, servers, communication platforms and embedded applications 4. Bus type: M.2 A+E KEY 5. Transmission medium: 1 x 2.5G RJ45 port 6. Transmission rate: 2.5G/1000/100/10Mbps 7. Network mode: supports 2.5G and 1G Lite mode 8. Network topology: - Supports IEEE1588v1, IEEE1588v2, IEEE80.2AS time synchronization - Supports IEEE802.1Qav credit-based shaping algorithm - Support IEEE802.1P Layer 2 priority encoding - Support IEEE802.1Q VLAN tagging - Support IEEE802.3az-2010 - Support IEEE802.3bz-2016 (NGBASET) - Support full-duplex flow control (IEEE802.3x) 9. Features: - Auto-negotiation with extended next page function - Support for exchange/sex/skew correction- Crossover detection and automatic correction - Support hardware ECC (error correction code), hardware CRC (cyclic redundancy check) function - Support PCI MSI (Message Signal Interrupt) and MSI-X - Support ECMA-393 ProxZzzy standard for sleeping host - Support LAN wake-up and RealWow technology (remote wake-up) Packing list: - M.2 A+E RTL8125B main card x 1 - RJ45 network cable terminal x 1 - Short iron sheet x 1 - CD drive disc x 1

Specifications

SKU

TBD06060219

Category

Computer & Networking › Computer Components › Add-on Cards

Weight

0.064 kg

Delivery

Standard delivery
