TPA7498e Power Amplifier Board Bluetooth Module Stereo 2.1 Audio Treble and Bass Control Subwoofer

Product Description

1. Model: XY-S220H 2. Item: 2.1 channel Bluetooth-compatible audio amplifier board 3. Power supply: above DC12-38V/10A 4. Bluetooth-compatible version: 5.1 5. Audio channel: 2.1 channel 6. Audio input: Bluetooth-compatible+AUX+U disk+USB sound card 7. Audio output: left and right channels + subwoofer 8. Frequency range: 20HZ--20KHZ 9. Volume adjustment: high-end encoder knob adjustment, smooth feel 10. Left and right channel maximum output power: 160W/4ohms----36V DC, 80W/8ohms---36V DC 11. Subwoofer maximum output power: 220W/3ohms----36V DC, 160W/4ohms----36V DC 12. Protection mechanism: overvoltage, undervoltage, clipping, short circuit, overheating, etc. 13. Unique function: Support Sinilink-APP to modify the Bluetooth-compatible name, set the 14. Bluetooth-compatible password, turn off/on the prompt tone

Specifications

SKU

DIY0553

Category

Consumer Electronics › DIY Parts & Components › Breadboard / Amplifier Board

Weight

0.409 kg

Delivery

Standard delivery
